SF Racing Air Struts for 2010-2017 Chevrolet Equinox (CG1)

SF Racing Air Struts for 2010-2017 Chevrolet Equinox (CG1)

$1,795.00 USD
$1,900.00 USD $1,795.00 USD
Sale Out of stock
Shipping calculated at checkout.

Listed for: 2010-2017 Chevrolet Equinox (CG1)Fitment notes & questions

SF Racing Air Struts for the 2010-2017 Chevrolet Equinox (CG1) are the best coilovers available for street-driven cars. SF Sport Coilovers were designed to give a wide range of ride height adjustability without reducing the spring travel. Each corner of the car has 32 levels (or clicks) of damping adjustability. This combines both the rebound and compression into one adjustment knob. The coilovers also use rubber top mounts to help reduce the noise that typically comes with high performance aftermarket coilovers. SF Coilovers come standard with an anodized coating to protect against rust and corrosion caused by extreme use and harsh external elements.

SF Racing parts are manufactured from high quality products sourced from around the world while still maintaining a very affordable price. SF Racing Sport Coilovers are the perfect setup for your daily driver.

Features

  • Monotube Damper Design – Improves heat dissipation and reduces oil leakage.
  • 32-Level Adjustable Damping – Fine-tune rebound and compression for ideal ride quality.
  • Adjustable Ride Height – Lowers 1-2.5 inches below factory height without sacrificing suspension travel.
  • Independent Lower Mount Adjustment – Maintains shock and spring integrity while adjusting height.
  • T6-6061 Aluminum Construction – Lightweight, corrosion-resistant anodized top mounts, perches, and collars.
  • Electroplated Shock Body – Zinc-coated for rust protection.
  • Low-Friction, Pressure-Resistant Housing – Ensures smooth damping and longevity.
  • Pillowball or Reinforced Rubber Top Mounts – Reduces noise while improving handling.
  • SAE9254 Japanese Cold-Wound Springs – Durable and consistent performance.
  • Japanese NOK Seals & Italian IP Damping Oil – Prevents leaks and ensures high-performance damping.
  • Integrated Dust Boots & Bump Stops – Protects components from debris and wear.
  • 100% Bolt-On Replacement – No modifications required (unless otherwise stated in the Specifications section).

Specifications

Part Number SF-CH09-02-AS
Vehicle 2010-2017 Chevrolet Equinox
Drivetrain
Chassis CG1
Damper Model Air Struts
Damping Adjustability 1-Way: Rebound and Compression
Damper Size - Front 52mm diameter
Damper Size - Rear 46mm diameter
Spring Rates - Front 12 kg/mm
Spring Rates - Rear 12 kg/mm
Top Mounts - Front Aluminum with Rubber Bushings
Top Mounts - Rear Not Applicable
Suspension Design - Front True Coilover
Suspension Design - Rear Divorced (Separate shock and spring)
Notes -
View full details

Before you order: Chevrolet Equinox fitment and setup

Air suspension lets you raise and lower the car on demand, so a Chevrolet Equinox can sit low when parked and still clear driveways and speed bumps.

Fitment notes

  • Listed for: 2010-2017 Chevrolet Equinox (CG1).
  • Model years: 2010-2017. Check your car's year falls inside this range.
  • Chassis code CG1: parts for other chassis codes of the same model usually won't fit.
  • Factory adaptive dampers: if your car has electronic or adaptive suspension, check whether the listing covers it or needs a cancellation kit.
  • Specs, lead time and warranty come from SF Racing and can change. The details above this guide are the latest we have.

Not sure it fits? Send us your year, make, model, trim and drivetrain and we'll check with the supplier before you order.

Ask about fitment

Plan the whole job

  • An alignment. Any change in ride height changes camber and toe. Set your final height first, then align.
  • Camber and toe adjustment. Bigger drops often need adjustable arms or camber plates to align properly. See alignment and camber kits.
  • Management. Air struts need a compressor, tank and controller unless the listing says they're included.
  • Wheel and tire clearance. Check clearance at full lock and full compression, especially with wider wheels.

More for your car: Chevrolet Coilovers & Suspension · All Air Suspension

Questions about Chevrolet Equinox air suspension

Will this fit my Chevrolet Equinox?
It is listed for the 2010-2017 Chevrolet Equinox (CG1). Check your year, model, drivetrain and chassis code against the product title. If anything is different, contact us and we will confirm fitment with the supplier before you order.
Do I need an alignment after installing air suspension?
Yes. Changing ride height changes camber and toe. Set your final height, let the suspension settle, then get the car aligned.
How low can I go?
It depends on the adjustment range the brand lists, your wheels and tires, and how you use the car. Most cars that are driven hard work best with a modest drop that leaves enough suspension travel.
Where do specs and warranty details come from?
From SF Racing. We sell parts from several brands and suppliers, and each one sets its own specs, lead times and warranty terms. The product details above are the latest we have.
